BAUSCH Advanced Technology Group Vial Filling Line, New

New and Unused BAUSCH Advanced Technology Group (BATG) vial filling line consisting of the following:

1. BAUSCH Type 721 Manual Debagging/-Lidding Station (including outer debagging).
2. BAUSCH Type 411 UV Light Tunnel to decontaminate outer surfaces.
3. BAUSCH Type 534 Filling and Stoppering Machine (including pre-gazing).
   • Max of 150 containers/min (9,000/hour) for 2R vials and 110 containers/min (6,600/hour) for 6R vials.
4. BAUSCH Type 551 Crimping Machine.
5. BAUSCH Type 309 Outside Washing Machine.
6. BAUSCH Type 603 Labeling Machine (with dual tray discharge).

Containment System: Isolator-based, with oRABS for material intake.

Electrical Requirements: 400V, 50Hz (European standard; compatible with U.S. power via transformer).

Includes change parts for vials:

• 2 ml injection vial (2R) (16 mm outer diameter x 35 mm height)
• 6 ml injection vial (6R) (22 mm outer diameter x 40 mm height)
• 10 ml injection vial (10R) (24 mm outer diameter x 45 mm height)
• 20 ml injection vial (20R) (30 mm outer diameter x 55 mm height)
• 30 ml injection vial (30R) (30 mm outer diameter x 75 mm height)

The line is currently still at the manufacturer.

Prosys Aseptic Isolator with Thermo Scientific Heraeus Multifuge X3 Centrifuge

ProSys S06428 Containment and Sampling Technology is a single-chamber closed-barrier system protecting from cross-contamination between a process and the surrounding laboratory. The Isolator is rated ISO5.  (International Standards Organization) (for particle count) environment in operation. An integration with a bio-decontamination system allows parametric surface bio-decontamination and their ventilation systems, before and after processes.  The isolator suite system consists of one chamber with a central H2O2 (Hydrogen peroxide) vapor generator.  An MUA (Make Up Air) ventilation system ensures controlled pressure vs. the surrounding room, as well as constant fresh-air renewal.  The incoming air is supplied from the surrounding room and extracted back to the room.  A central PLC (Programmable Logic Controller) based control system controls the isolator, with HMI (Human Machine Interface) centralizing all commands and monitoring data.  A central H2O2 vapor generator will sit on a skid. Pipe work will directly connect the generated H2O2 vapor from the generator to the isolator.  After the bio-decontamination cycle, H2O2 vapor is directed to the room via a catalytic converter.  The isolator also has its own High H2O2 monitoring sensor.  The Isolator is supplied with a glove test kit to detect glove leaks.  The entire isolator is cleanable, with minimum crevices/ledges, and composed of non-shedding materials. Thermo Scientific Heraeus Multifuge X3 Centrifuge, SN S06428.

30 Sq Meter Optima Pharma Freeze Dryer Lyophilizer, Model FD S-30

Unused 30 Sq Meter Optima Pharma Freeze Dryer Lyophilizer, Model FD S-30, stainless steel construction, (13) usable shelves, 1520mm x 1520mm, 120mm shelf spacing, stoppering, job# 4039023, built 2020.  Unit was never installed still on original shipped skids from manufacturer.

Glatt CPS 3 Fluid Bed Dryer

Used Glatt CPS 3 Fluid Bed Dryer, model CPS 3 Lab System, Roto-granulator chamber, made in 2011, S/N 11565.
